87
Management Ethernet port LEDs
S5560-30C-EI&S5560-34C-EI&S5560-54C-EI&S5560-30F-EI&S5560-30C-PWR-EI&S5560-54C-PWR-
EI
The S5560-30C-EI, S5560-34C-EI, S5560-54C-EI, S5560-30F-EI, S5560-30C-PWR-EI, and
S5560-54C-PWR-EI switches provide an ACT/LINK LED to indicate the operating state of the
management Ethernet port.
Table 37 Management Ethernet port LED description for the S5560-30C-EI, S5560-34C-EI,
S5560-54C-EI, S5560-30F-EI, S5560-30C-PWR-EI, and S5560-54C-PWR-EI switches
Management Ethernet port
LED (ACT/LINK) status
Description
Steady green A link is present on the port.
Flashing yellow The port is sending or receiving data.
Flashing yellow (3 Hz) The port has failed POST.
Off No link is present on the port.
S5560-54QS-EI
The S5560-54QS-EI switch provides one LINK LED and one ACT LED for each management Ethernet
port.
Table 38 Management Ethernet port LEDs description for the S5560-54QS-EI switch
LED mark Status Description
LINK
Off The management Ethernet port is not connected.
Steady green The management Ethernet port is operating at 10/100/1000 Mbps.
ACT
Off The management Ethernet port is not receiving or sending data.
Flashing yellow The management Ethernet port is sending or receiving data.
Expansion card status LED
The S5560-30C-EI, S5560-34C-EI, S5560-54C-EI, S5560-30F-EI, S5560-30C-PWR-EI, and
S5560-54C-PWR-EI switches provide an expansion slot at the rear. The expansion card status LED on the
front panel indicates the operating state of the expansion card.
Table 39 Expansion card status LED description
LED mark Status Description
SLOT
Steady green The expansion card is in position and is operating correctly.
Flashing yellow
The switch does not support the card model, or the card has
failed.
Off The expansion slot is empty.
