11
No.
Description
Mark
2 PCIe riser connector 2 (for processor 2) RISER2 PCIe X16
3 Fan connector 2 for the OCP 3.0 network adapter -
4
OCP 3.0 network adapter connector
2/Serial & DSD
module connector
OCP2&DSD&UART CARD
5 PCIe riser connector 1 (for processor 1) RISER1 PCIe X16
6 Server management module slot BMC
7 Fan connector 1 for the OCP 3.0 network adapter OCP1 FAN
8 OCP 3.0 network adapter connector 1 OCP1
9 SlimSAS connector 3 (x4 SATA) SATA PORT3
10 AUX connector 9 for mid drive backplane AUX9
11 Mid drive backplane/Riser card AUX connector 7 AUX7
12 SlimSAS connector 2 (x4 SATA) SATA PORT2
13 SlimSAS connector 1 (x4 SATA or M.2 SSD) M.2&SATA PORT1
14 Front I/O connector RIGHT EAR
15 M.2 SSD AUX connector M.2 AUX
16
Fan connector 4
J245
17 Liquid Leakage Detection module connector LEAKDET
18 LCD smart management module connector DIAG LCD
19 MCIO connector C1-P4A (for processor 1) C1-P4A
20 MCIO connector C1-P4C (for processor 1) C1-P4C
21 Fan connector 3 J104
22 MCIO connector C1-P3C (for processor 1) C1-P3C
23 MCIO connector C1-P3A (for processor 1) C1-P3A
24 Power connector 3 for front drive backplane PWR3
25 Power connector 2 for front drive backplane PWR2
26 Connector for the thermal sensor module at the air inlet -
27 Power connector 1 for front drive backplane PWR1
28 Fan connector 2 J94
29 MCIO connector C2-P4A (for processor 2) C2-P4A
30 AUX connector 3 for front drive backplane AUX3
31 MCIO connector C2-P4C (for processor 2) C2-P4C
32 MCIO connector C2-P3C (for processor 2) C2-P3C
33 Fan connector 1 J96
34 AUX connector 2 for front drive backplane AUX2
35 AUX connector 1 for front drive backplane AUX1
36
MCIO connector C2-P3A (for processor 2)
C2-P3A
37 Chassis-open alarm module connector INTRUDER
