H3C UniServer R4900 G6 Ultra User Manual

0
Server specifications
Components
Figure 1 Server components
Item
Description
(1) Chassis access panel N/A
(2) Mid drive cage Installed in the server to accommodate drives.
(3
) Standard PCIe network
adapter
Installed in a standard PCIe slot to provide network ports.
(4) System battery Supplies power to the system clock to ensure system time correctness.
(5) Storage controller
Provides RAID capability to SAS/SATA drives, including RAID
configuration and RAID scale-
up. It supports online upgrade of the
controller firmware and remote configuration.
(6) NVMe VROC module
Works with Intel VMD to provide RAID capability for the
server to
virtualize storage resources of NVMe drives.
(7) GPU module Provides computing services such as graphics processing and AI.
(8) Riser card Provides PCIe slots.
(9) OCP adapter
Provides one slot for installing an OCP network adapter and two slots for
installing drives at the server rear.
(10) Serial & DSD module Provides one serial port and two SD card slots.
(11) Memory
Stores computing data and data exchanged with external storage

H3C UniServer R4900 G6 Ultra Specifications

General

Processor	Intel Xeon Scalable Processors
Maximum Processors	2
Memory Slots	32 DIMM slots
Form Factor	2U Rack Server
Storage	Up to 24x 2.5" or 3.5" drives
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Expansion Slots	Up to 8 PCIe slots
