H3C UniServer R4900 G6 Ultra - System Board; System Board Components

10
Port
Type
Description
HDM dedicated
network port
RJ-45
Establishes a network connection to manage HDM
from its Web interface.
Power receptacle Standard single-phase Connects the power supply to the power source.
System board
System board components
Figure 12 System board components
Table 13 System board components
No.
Description
Mark
1 PCIe riser connector 3 (for processor 2) RISER3 PCIe X16
