H3C UniServer R4900 G6 Ultra - Rc-2 Hhhl-R3-2 U-G6

33
RC-2HHHL-R3-2U-G6
Figure 50 RC-2HHHL-R3-2U-G6
(1) PCIe5.0 x16 (8,4,2,1) slot 8
(2) PCIe5.0 x16 (8,4,2,1) slot 7
PCIe5.0 x16 (8,4,2,1) description:
• PCIe5.0: Fifth-generation signal speed.
• x16: Connector bandwidth.
• (8,4,2,1): Compatible bus bandwidth, including x8, x4, x2, and x1.
NOTE:
This type is riser card is not supported when liquid-cooled modules are installed on the server.
