H3C UniServer R4900 G6 Ultra User Manual

49
Table 23 Riser card and PCIe module compatibility (4)
Riser
card
model
Riser card
location
PCIe slots
on a riser
card
PCIe
slot or
connector
description
PCIe
module for
PCIe slot or
connector
PCIe
slot
power
capabi
lity
Proc
esso
r
RC-1FH
FL-R3-2
U-G6
PCIe riser
connector 3
Slot 7
PCIe5.0 x16
(16,8,4,2,1)
FHFL 75 W
Proce
ssor 2
RC-2HH
HL-R3-2
U-G6
PCIe riser
connector 3
Slot 7
PCIe5.0 x16
(8,4,2,1)
HHHL 75 W
Proce
ssor 2
Slot 8
PCIe5.0 x16
(8,4,2,1)
HHHL 75 W
Proce
ssor 2
RC-2FH
FL-R3-2
U-G6
PCIe riser
connector 3
Slot 7
PCIe5.0 x16
(8,4,2,1)
FHFL 75 W
Proce
ssor 2
Slot 8
PCIe5.0 x16
(8,4,2,1)
FHFL 75 W
Proce
ssor 2
Table 24 Riser card and PCIe module compatibility (5)
Riser
card
model
Riser card
location
Slot or
connector
on the
riser card
PCIe
slot or
connector
description
PCIe
module for
PCIe slot or
connector
PCIe
slot
power
capabi
lity
Proc
esso
r
RC-2HH
HL-R4-2
U-G6
PCIe riser
connector 4
Slot 9
PCIe5.0 x16
(8,4,2,1)
HHHL 75 W
Proce
ssor 1
Slot 10
PCIe5.0 x16
(8,4,2,1)
HHHL 75 W
Proce
ssor 2
SLOT 1
cable
x8 MCIO
connector
Connected to MCIO
connector C1-P2C on
the system, providing
an x8 PCIe link for slot 9
N/A
Proce
ssor 1
SLOT 2
cable
x8 MCIO
connector
Connected to MCIO
connector C2-P2C on
the system board,
providing an x8 PCIe for
slot 10
N/A
Proce
ssor 2
AUX AUX connector
Connected to connector
AUX8 on the system
board
N/A N/A
PWR
Power
connector
Connected to connector
PWR4 on the system
board
N/A N/A

H3C UniServer R4900 G6 Ultra Specifications

General

Processor	Intel Xeon Scalable Processors
Maximum Processors	2
Memory Slots	32 DIMM slots
Form Factor	2U Rack Server
Storage	Up to 24x 2.5" or 3.5" drives
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Expansion Slots	Up to 8 PCIe slots
