Figure 2 Product compoments
1 EZ analyzer 4 Lock washer, M8 (4x) 7 Tube fittings and ferrules
4
2 Mounting brackets (2x) 5 Flat washer, M8 (4x) 8 Key for electrical compartment
3 Hex bolt, M8 × 16 (4x) 6 Reagent and solution bottles
4
9 Power cord
Section 5 Installation
D A N G E R
Multiple hazards. Only qualified personnel must conduct the tasks described in this section of the
document.
5.1 Installation guidelines
W A R N I N G
Fire hazard. The user is responsible to make sure that sufficient precautions are taken when the
equipment is used with methods that use flammable liquids. Make sure to obey correct user
precautions and safety protocols. This includes, but is not limited to, spill and leak controls, proper
ventilation, no unattended use, and that the instrument is never left unattended while power is
applied.
C A U T I O N
Chemical exposure hazard. Obey laboratory safety procedures and wear all of the personal protective
equipment appropriate to the chemicals that are handled. Refer to the current safety data sheets
(MSDS/SDS) for safety protocols.
4
Quantity and type is based on the supplied analyzer.
