HAIMER Basic - Power Clamp PRESET; Power Clamp Basic

16
Operating Manual
POWER CLAMP
English
Quality Wins.
© 2021/09 Haimer POWER CLAMP
2.5.3 Power Clamp PRESET
14 Tool holder
42 Chuck holder
43 Stop clamp
44 Measuring head
45 Tool stop
46 Handwheel
47 Clamping lever
48 Stop clamp
ESC
43
49
42
2.5.4 Power Clamp Basic
4 Connecting plug
Inductor
5 Mains switch
6 Linear guide inductor
7 Handle with brake
8 Start key inductor
9 Energy cable inductor
10 Spring tensioner
11 Operational display lamp
13 Inductor
14 Tool holder
17 Operation and display field
42 Chuck holder
43 Stop clamp
49 Stop disks
42
48
46
44
45
47
43
Device Description
