Operation
T-slot milling cutters
When milling T-slots the cutting diameter is greater than
the shank.
• Rotate the coil into the position shown.
• Release the locking pin (27) and lock it by turning it
by 90°.
• Set the aperture to the largest Ø.
• Only for coil VS 32 H and T-slot milling cutter Ø > 34 mm:
Unlock the ferrite ring (30) by turning it counterclock-
wise and take it out.
• Lower the coil onto the chuck.
• Unlock the locking pin (27).
• Close the aperture until the locking pin (27) clicks into
place again.
• Only coil VS 32 H:
Insert the ferrite ring (30) again once the shrink fit
operation has been completed.
Ultra-short chucks and special shapes
In the case of very short chucks it can happen that the coil
with its stop element does not lie on the chuck but instead
its underside sits on the collar of the chuck.
• Adjust the coil to the item specified for the chuck.
• Pull the locking pin (27).
• Set the coil to the clamping diameter of the chuck (see
the display or the markings on the coil)
5.3.4.2 Automatically adjustable coil VS 32 M
Start the positioning with the coil raised up.
• Select the shrink fit parameters from the display.
The coil position is shown in inverse.
• Press the key
.
The coil travels automatically to the selected position.
The position on the display is displayed normally again.
Note:
In the case of the VS 23 M coil the settings are travelled
to automatically by means of actuators. Objects or parts
of the body could be trapped and crushed.
• Never reach into the opened aperture.
• The clamping forces are low. If parts of the body or
objects get trapped (the coil does not reach the de-
sired position), immediately open the aperture and
coil again.
• With
the aperture opens fully again.
ESC
Standard
Ø 14-16
Position # 5
