Back Panel
23. Rear handlebars connecon
2 4 . Rear display USB connecon
2 5 . Main On/O power switch
26. Power cord connecon
2 7 . Reserved for second video camera
2 8 . Reserved for HQ Pro-Stcher
2 9 . Stch regulator
30. Laser stylus connecon
31. Reserved for HQ Pro-Stcher power
32. Rear display power connecon
32
23
2 4
2 5
26
31
30
2 8
2 7
2 9
