HAO INSTECH HY8200 Series User Manual

HY8200 User’s Manual
7
1.Product Overview
1.1 Product Overview
HY8200 series DC electronic load contains 3 models:HY8211、HY8212 and HY8213.
HY8200+ series DC electronic load is equipped with 2.8 inch LCD, which is convenient and
simple to operate and has a fashionable appearance. The electronic load has a wide range of
power measurement, voltage and current sampling rate up to 4.8MHz, test resolution up to
1mV/1mA, while equipped with rich test functions and modes for your choice. The equipment is
equipped with RS232 communication module, which is flexible to meet various field test
conditions and is convenient to connect seamlessly with automated production lines and
automatic test systems (ATS). The electronic load is stable and widely used to meet various
testing requirements.
1.1.1 Characteristics

Four modes: CC/CV/CR/CP

Resolution is up to 1mV/1mA

Minimum rise time of dynamic current test: 500us

Sampling rate of voltage/current is up to 4.8MHz
 Multi-mode battery discharge test
 List mode, support automatic test
 Independent short-circuit test function
 Over-voltage/low-voltage/over-current/over-power/overheat/anti-reverse
connection protection
 Support RS232 communication interface

Matched upper computer software for remote control and monitor
This chapter mainly covers the following contents:
Product Series(Features and Technical Specifications)
Front Panel
Rear Panel
Model
Channel quantity
Measurement range
Voltage
Current
Power
HY8211
Single channel
0~150V
0~40A
0~400W
HY8212
Dual channel
0~150V
0~20A
0~200W
HY8213
Single channel
0~500V
0~15A
0~400W

HAO INSTECH HY8200 Series Specifications

General

Brand	HAO INSTECH
Model	HY8200 Series
Category	Measuring Instruments
Language	English
