HY8200 User’s Manual
25
After the parameter is set, press ON1 or ON2 to input the list file to the channel.
Operation steps:
1. After the instrument is boot-up, press CH key to select the channel, yellow wireframe area is the
selected channel and it will display the prompt of CH1 or CH2 at top of the screen
(HY8211/HY8213 single channel don’t need to choose.)
2. Press Mode key to enter the selection interface, use rotary knob or direction key to select list mode
and then press Enter key to enter the set interface.
3. Rotate the rotary knob to select the parameter to adjust, press Enter key to change and press it
again to save the setting.
Set list parameter (group number, step, repeat times and mode), press Enter key to enter the
adjustable state, use rotary knob to select the mode or adjust the numerical value of the parameter
and then press Enter to complete the setting.
Set mode parameter (mode, check), move the cursor to the parameter, press Enter key to go
through different parameter option and stay at the selected parameter, use direction key or rotary
konb to enter the next parameter setting.
Set mode parameter (constant value, timing, upper, lower), move the cursor to the parameter,
press Enter key and xxxx at the bottom of the screen will turn to the specified value, use rotary
konb to adjust the numerical value and then press Enter key to complete the setting.
Caution:
During the setting, if the setting value exceeds the limit, ERROR: DATA IS OVER LIMIT prompt will
pop out. Press Enter key to cancel it. The value should adjust to within the range by the rotary knob
to complete the setting. Otherwise, pop-up prompt will continue to appear.
4. After the parameter is set, press ON key to enter list test interface (press ON1 to enter CH1, press
ON2 to enter CH2).
5. Press ON key to operating, press ON key again to stop the operation.
4.1.7 Battery Test
Battery test is used to detect the battery capacity. Battery capacity is an important index of battery, it
reflect the using time and reliability issue of battery.
During the battery test, the voltage will decreasing with the increasing of discharge time, so it need to set
the cut-off voltage, the test will stop when it meets the cut-off voltage.
Battery mode parameters:
