HAO INSTECH HY8200 Series User Manual

HY8200 User’s Manual
8
 Power cutoff memory
 Smart temperature controlled fans

Chinese/English display
1.1.2 Technical Specifications
Model
HY8211
HY8212
HY8213
Rated
value
0~40℃
Voltage
0~150V
0~150V
0~500V
Current
0~40A
0~20A(Single channel)
0~15A
Power
400W
200W x 2
400W
minimum
operating
voltage
2.0V @40A
2.0V @ 20A
3.0V @15A
CV mode
Range
0~15V
0~150V
0~15V
0.1~150V
0~50V
0~500V
Resolution
1mV
10mV
1mV
10mV
1mV
10mV
Accuracy
±（0.1%+0.1%FS)
±（0.1%+0.1%FS)
±（0.1%+0.1%FS)
CC mode
Range
0~4A
0~40A
0~2A
0~20A
0~1.5A
0~15A
Resolution
1mA
10mA
1mA
10mA
1mA
10mA
Accuracy
±（0.1%+0.1%FS)
±（0.1%+0.1%FS)
±（0.1%+0.1%FS)
CR mode
Range
0.05Ω~7.5kΩ
0.05Ω~7.5kΩ
0.1Ω~25kΩ
Resolution
12bit
12bit
12bit
Accuracy
±（0.3%Vin/Rset+0.2%IF.S)
±（0.3%Vin/Rset+0.2%IF.S)
±（0.3%Vin/Rset+0.2%IF.S)
CP mode
Range
400W
200W (Single channel)
400W
Resolution
10mW
10mW
10mW
Accuracy
±（0.1%+0.5%FS)
±（0.1%+0.5%FS)
±（0.1%+0.5%FS)
Dynamic
mode
T1&T2
100μS~50S/Res:100μS
100μS~50S/Res:100μS
100μS~50S/Res:100μS
Rising/
Falling
slope
0.08A/mS~0.4A/μS
0.04A/mS~0.2A/μS
0.03A/mS~0.15A/μs
Minimum
rising time
100us
100us
100us
Readback
Voltage
Range
0~15V
0~150V
0~15V
0~150V
0~50V
0~500V
Resolution
1mV
10mV
1mV
10mV
5mV
50mV
Accuracy
±（0.1%+0.1%FS)
±（0.1%+0.1%FS)
±（0.1%+0.1%FS)
Current
readback
Range
0~4A
0~40A
0~2A
0~20A
0~1.5A
0~15A
Resolution
1mA
10mA
0mA
10mA
1mA
10mA
Accuracy
±（0.1%+0.1%FS)
±（0.1%+0.1%FS)
±（0.1%+0.1%FS)
Readback
Power
Range
400W
200W
400W
Resolution
10mW
10mW
10mW
Accuracy
±
（
0.1%+0.5%FS)
±
（
0.1%+0.5%FS)
±
（
0.1%+0.5%FS)
Overpower Protection
Delay protection,
immediate protection
Overcurrent Protection
Delay protection, immediate protection
