In order to meet the various test needs, HY8200 series electronic load provides multiple test modes
for user, which includes dynamic test, list test and batter test.
Operation steps:
1. After the instrument is boot-up, press CH key to select the channel, yellow wireframe area is the
selected channel and it will display the prompt of CH1 or CH2 at top of the screen (HY8211/HY8213
single channel don’t need to choose.)
2. Press Mode key to enter the selection interface, use rotary knob or direction key to select CP mode
and then press Enter key to enter test interface.
3. Rotate the rotary knob to change the power value (constant power value).
4. Press ON key to operating, press ON key again to stop the operation.
4.1.5 Dynamic Test
HY8200 series electronic load has dynamic current load mode. In dynamic mode, user can set the
two constant parameter, the electronic load can switch the two constant value by set the operation
mode. The following table is an example of the set interface in this mode.
[Dynamic] [Local]
Operation mode
Continues
Repeat Times
01000
Low value
1.000
A
Timing of low scale
100.0
ms
High value
5.000
A
Timing of high scale
100.0
ms
Rising slope
0.100
A/us
Falling slope
0.100
A/us
Parameter of Dynamic Test
Dynamic Test
Description
Operation mode
Set operation mode:continuous, pulse, reversal
Low value
Set the parameter value of low scale
Timing of low scale
Set the load time of low scale
High value
Set the parameter value of high scale
Timing of high scale
Set the load time of high scale
Rising Slop
Set the rising slop
Falling Slop
Set the falling slop
Repeat Times
Set the repeat times
Operation Description of Dynamic Mode
1. Continuous Mode
