7 - Menu 3 Calibration
7.6
Menu 3.3 Boom
Menu 3.3.1 Width
Use the ¿ or ª keys or numeric keys to enter boom width.
Press # to confirm.
Menu 3.3.2 Number of sections
Use the ¿ or ª keys or numeric keys to set number of boom sections.
Press # to confirm.
Menu 3.3.3 Nozzles/section
Use ¿ or ª keys or numeric keys to set correct number of nozzles per section.
Press # to continue to next boom section.
Press # after the last section.
Menu 3.3.4 End nozzles and Bi-jet (optional)
If end nozzles or Bijet are fitted, it should be set up corresponding to the number of boom nozzles it covers.
1. In menu [3.3 Boom setup] go to the menu [3.3.4 End nozzles and Bi-jet].
2. Press #.
3. Select submenu corresponding to the type of end nozzle:
Menu 3.3.4.1 None
Menu 3.3.4.2 End nozzles fitted
Menu 3.3.4.3 Bi-jet fitted
4. Press #.
5. In the sub menus [3.3.4.2] and [3.3.4.3] set the value to the equivalent coverage by the boom nozzles. E.g. end nozzle
coverage is 5 feet. This is equal to 3 boom nozzles.
μ
ATTENTION! It is important that the volume applied from the end nozzle matches the volume applied under the
boom. This is a comparison of volume per minute per length. (Gallon/min/foot).
When the end nozzle is active, the area covered and volume sprayed is calculated and registered. If “Active boom
size” is displayed, it will show an increase when the end nozzle is activated.
