6 - Menu 2 Setup
6.3
Menu 2.2 Auto functions
Menu 2.2.1 Main ON/OFF
The Controller can be set to open the main ON/OFF function above a certain speed and close it below the same speed.
This allows the user to concentrate on driving. If the speed is set at zero, the function is deactivated. Suggested speed
setting is spraying speed less 20%.
When the Auto ON/OFF is active and the main switch and boom section switches are on, the boom status symbol has a bar
across that is blue.
Procedure is:
1. Go to menu [2.2 Auto functions]
2. Press #.
3. Select menu [2.2.1 ON/OFF].
4. Press #.
5. Set the desired minimum speed.
6. Press #.
±
WARNING! Remember to set the main ON/OFF switch to OFF before leaving the field, otherwise the main ON/OFF
will open under transport.
Menu 2.2.2 Foam Marker (optional)
The Controller can be set to operate the HARDI® Foam marker automatically through the main ON/OFF valve. When the
main ON/OFF is ON, it will automatically start the Foam marker.
Furthermore, the Foam marker can be set for up and back spraying or race-track (round and round) spraying.
Procedure:
1. Go to menu [2.2 Auto functions].
2. Press #.
3. Select menu [2.2.2 Foam marker]
4. Press #.
5. Select one of the below settings:
Setting Activity
[Disable] The marker will only follow the setting of the switch on the SetBox.
[Same side] The Terminal will automatically activate the same side for race-track spraying.
[Change side] The Terminal will automatically change side for up and back spraying.
6. Press #.
