14.1
14 - Technical specifications
Specifications
Specifications
Flow ranges for the flow transducers
Supply voltage 12 Volt DC
Controlled shutdown “low battery”: 9 Volt DC
Maximum supply: 16 Volt DC
Maximum peak: 28 Volt DC
Ambient temperature: 23°F to 158°F (-5°C to +70°C)
Memory: Flash PROM non-volatile
Digital transducers (option 2, 3 and 4): Square signal
Frequency: 0.5 Hz to 2 kHz
Trigger high: 4.0 to 12.0 Volt DC
Trigger low: 0.0 to 2.0 Volt DC
Analog transducers (option 1):
Supply: 12 V
Input: 4 to 20 mA
Minimum speed for volume regulation 0.3 mph (0.5 km/h)
Housing Housing identification (A) Flow range
g/min
Orifice
mm
PPU
value
S/67 One outside groove 2 - 30 13.5 485.00
S/67 No groove 4 - 70 20.0 225.00
S/67 Two outside grooves 20 - 160 36.0 60.00
