8 - Menu 4 T
oolbo
x
8.6
Menu 4.6 Speed simulation
How to us
e speed simulation
Speed may be simulated for certain pu
rposes. A two figure value may be
entered. Th
e state remains vali
d unti
l the Controller is restarted or the
value is set to “0”.
4.6 Speed simulation
4 .00
mph
Key
in sp
eed v
alue
.
T
o disable simulation key in 0 or power off
63
65
