Harris P7300 SERIES - Menu Navigation and Options

MM-013994-001, Rev. J
33
MENU
NAME
RADIO
DISPLAYS
USAGE NOTES
See Previous Page
Selected
Channel
“ChannelMenu”
Displays the current channel. Press to return to dwell display.
Scan Mode
“ScnModeMenu”
Use or to scroll through available scan modes (Normal, No Scan, or Fixed)
.
Press to return to dwell display.
Talk Group
Lock Out
“LockOutMenu”
Use or to choose a Talk Group for locking/unlocking. Press
to toggle “<”
on (locked out) and off.
Priority 2
Talk Group
“Priority2”
Use or to choose Priority 2 Talk Group. Press to return to dwell display.
Priority 1
Talk Group
“Priority1”
Use or to choose Priority 1 Talk Group. Press to return to dwell display.
Alerts Received
“Alerts Rcvd”
or oldest message
“No alerts” or alert message text scrolls in display. Use or to scroll through
all
messages.
Alert Destination
“Alert Dest”
Use or to choose a speed-dial number. Press 
to go to the “Alert Msg” menu.
Use or to scroll through “canned messages.” Press
to send message and
return to dwell display.
Speed Dial
“Speed Dial”
Use or to choose a speed-dial number and press PTT to place call.
Profile Selection
“ProfileMenu”
Use or to choose an available profile. Press to return to dwell display.
Talk Group
Selection
“TalkGrpMenu”
Use or to choose a Talk Group in current profile. Press
to return to dwell
display.
Status LED
“Status LED”
Use or to toggle status led “On” or “Off.” When On, the LED flashes red when
the radio transmits, green when receiving, and amber when in emergency. When Off,
the LED will not light at all.
Status Message
“Status Msg”
Use or to scroll through available messages. Press to send the selected
message.
Request to Talk
Message
“RTT Msg”
Use or to scroll through available messages. Press to send the selected
message.
V-TAC Client
Mode
“Client Mode”
Use or to choose Client Mode (Network, XCOV, XCOV-TG, or SOI).
Emergency
Dismiss
“EmgDismiss”
Use or to choose emergency Talk Group. Press to toggle “<
” on (dismiss)
and off.
See Next Page
