MM-013994-001, Rev. J
69
6. Press three times to add as a Priority 1 group.
7. Press to re-start scanning.
10.12.2 P7350 Model
1. Press to toggle scan OFF and verify is not displayed.
2. Select group or channel.
3. Press once to remove group or channel from the list.
4. Press once to add as a normal group or channel.
5. Press twice to add as a Priority 2 group.
6. Press three times to add as a Priority 1 group.
7. Press to re-start scanning.
10.13 MENU
The Menu function accesses features that are not available directly from the keypad. The order and actual
menu items available is configurable through programming. Upon radio power-up, the menu item that is
at the top of the menu list will always be displayed first. Subsequent access to the menu function will
return the last menu item that was shown in the display and cursor position.
1. To enter the menu mode, press .
2. Upon entering the menu selection mode, Menu options will appear in the display (see Figure 10-8).
Figure 10-8: Menu Display
3. The radio will continue to receive and transmit normally while in the menu function.
4. To scroll through the menu options, use the or
keys. When the required menu item has
been found, align the cursor with the option then press to select it. The menu item's parameter
setting shown in the display can now be changed by using or
to scroll through the list of
parameter values.
5. Once the desired setting is reached, press to store the value and return the menu option selection
level.
For menu items that display radio information, pressing or
will scroll through a list of
informational displays. Possible menu items are listed in Table 10-6.
10.13.1 Menu Item Selection Process
An example of the backlight menu item selection process and menu item parameter change is shown in
Figure 10-9.
1. Press . The menu mode is entered.
2. Press or
until the display shows:
