Harris P7300 SERIES User Manual

MM-013994-001, Rev. J
68
METHOD 3: (P7370 model radios only) Direct Access: Press to enter the system select mode.
Press the numeric key, which is mapped to the desired system. Press . The radio
will move to the selected system.
If system selection is programmed to the System/Group/Channel control knob, direct
access to systems will not be available. Pressing or
will scroll through
different sets of 16 systems each (banks) if more than 16 systems are programmed into
the radio. The systems within each bank are then selectable via the
System/Group/Channel control knob as described previously in METHOD 1.
Example:
System: 1 = North Group: 1 = Group 1
2 = South 2 = Group 2
3 = East 3 = Group 3
4 = West 4 = Group 4
1. Press . (South is the currently selected system.)
2. Press . (Press 4 to select “West” system.)
3. Press . (West is the newly selected system.)
10.11 GROUP/CHANNEL SELECTION
Several methods can be used to select a new group or channel.
METHOD 1:
From the Control knob: If group selection is programmed to the System/Group/Channel
control knob, select a group by turning the System/Group/Channel control knob to the
desired group
number position. The display registers the new group name on line two.
If the knob is moved to a position greater than the number of programmed groups, the
highest programmed group will remain selected. The
button can be programmed to
provide access to a “2
nd
bank” of 16 group number positions (17-32).
METHOD 2:
From keypad: If group selection is programmed as the primary function of
and
select a group by pressing or
to scroll through the group list. The
display registers the new group name on line two.
METHOD 3:
(P7370 model radios only)
Direct Access: Press
to enter the group select mode.
Press the numeric key mapped to the desired group. Press
.
The radio will move
to the selected group.
10.12 MODIFY SCAN LIST
10.12.1 P7370 Model
1. Press to toggle scan OFF and verify is not displayed.
2. Select group or channel.
3. Press once to remove group or channel from list.
4. Press once to add as a normal group or channel.
5. Press twice to add as a Priority 2 group.
NOTE
