MM-013994-001, Rev. J
72
10.14 BACKLIGHT ADJUST
1. Press to access the menu.
2. Press or
to scroll through menu until “BCKLGHT” appears.
3. Press to select Backlight menu.
4. Press or
to scroll through available settings OFF, 1 through 6.
5. Press to select new backlight setting.
10.15 CONTRAST ADJUST
1. Press to access the menu.
2. Press or
to scroll through menu until “CONTRAST” appears.
3. Press to select Contrast menu.
4. Press or
to adjust contrast setting from 1 - 4.
5. Press to select new contrast setting.
10.16 DECLARING AN EMERGENCY
1. Press and hold the red Emergency/Home button (the length of time is programmable; check with the
system administrator).
2. *TXEMER* will flash in the display, plus and will be displayed. After 2-3 seconds the transmit
icon will turn off.
3. *TXEMER* and will remain until the emergency is cleared. See Section 10.22 for additional
emergency operation.
4. Press the PTT and will reappear.
5. Release PTT when the transmission is complete.
10.17 LOCKING/UNLOCKING KEYPAD
1. Press button.
2. Within 1 second, press the button on the side of the radio.
10.18 HIGH/LOW POWER ADJUSTMENT
Transmit power adjustment is possible if enabled through programming. Within conventional systems,
transmit power is adjustable on a per channel basis. Within EDACS trunking systems, transmit power is
adjustable on a per system basis.
There are two ways to toggle between high and low power, described in Sections 10.18.1 and 10.18.2.
10.18.1 Using the Menu Button
1. Press .
2. Using the or
keys, scroll until the cursor (>) appears to the left of “TX POWER” in the
display.
