FEATURE DISPLAY
PARAMETER
SETTING
COMMENT
Add/Delete Scan List
SCAN A/D
N/A
Add or Delete from Scan List.
Select OpenSky mode
MODE
Allows you to activate OpenSky mode.
Message MSG
Permits the transmission of a preprogrammed message to a
P25 or EDACS site.
ProFile
PROFILE
ON/OFF
Toggles ProFile On/Off.
Talkaround
TALKARND
ON/OFF
Conventional Only. Toggles Talkaround feature ON/OFF.
Select Telephone
Numbers From Phone
List
PHONE N/A EDACS and P25 trunked.
Data Operation
NO DATA
ON/OFF
EDACS and P25 trunked. Toggles Data Operation ON/OFF.
Select Individual Call
from IC List
INDV N/A EDACS and P25 modes.
Select Group
GRP
N/A
EDACS and P25 modes.
Feature Encryption
Display
FEATURES
N/A
Indicates current features programmed into the radio as well
as certain information required to add features to the radio.
Informational display only. No user selectable settings.
System Scan Enable
SYS SCAN
ON/OFF
Toggles System Scan feature ON/OFF.
Talk-around
TALK
Toggles Talk-Around ON/OFF.
Type 99 Enable
T99 EN
ON/OFF
Toggles Type 99 Decode ON/OFF.
Table 10-7: Information Display
RADIO ID
XXXXXXXX
LID in EDACS/EA In CONV it has no
meaning.
RAM SIZ RAM Size
FLSH SIZ Flash Size
RF BAND Frequency Band
PERS VER Software Version
DSP DATE Date DSP code was built.
DSP TIME Time DSP code was built.
DSP FEAT The DSP Features supported by the
DSP code, in Hexadecimal.
Bit mapped (see IPC spec for details):
• 0x0001 – Conventional
• 0x0002 – EDACS
• 0x0010 – AMPF
• 0x0020 – undefined
DSP VER DSP Software Version
FLSH VER FLASH Software
ex: P73U0102
P=portable, 73=7300 radio,
U=unencrypted, 01=major revision (>50
means unreleased code), 02=minor
revision
HARRIS
(C) 2012
Copyright
PERSNLTY Personality Name
BLD DATE Date host (ARM) code was built.
BLD TIME Time host (ARM) code was built.
