9.8 BASIC MENU STRUCTURE
Table 9-5 illustrates the basic P7300 OpenSky menu structure. Menu items will vary depending upon
system programming, radio hardware, and optional configurations. All menus except the dwell display
menu can be turned off by network administration personnel.
Table 9-5: Basic P7300 OpenSky Menu Structure
MENU
NAME
RADIO
DISPLAYS
USAGE NOTES
To/From Dwell
Display
Engineering
Display
bit-error rates,
RSSI data, sync
status, current
channel and
registration status
Displays radio system connection data. For engineering use.
Silent
Emergency
“SilentEmerg”
Use or to toggle between OFF/ON. Press to enable.
Operating Mode
“App Mode”
Use or to choose an available mode (
OTP, OCF, or ECP). Press
and
confirm (Y/N) with or and

again.
GPS Fix
“GPS”
GPS latitude and longitude position of currently tuned-
to base station [“GPS (Site)”] or
V-TAC (“GPS”) scrolls across top line of the display. “GPS (Aged)” indicates V-TAC
coordinates haven’t been updated for more that 2 minutes.
User ID
“User ID”
User’s identification/name scrolls across top line of the display (if programmed).
IP Address
“IP Address”
Radio’s Internet Protocol (IP) address scrolls across top line of the display.
Station
Identification
“Station ID”
Station’s identification/name scrolls across top line of the display (if programmed).
Stealth Mode
(display backlight
is disabled)
“StealthMenu”
Use or to turn Stealth Mode “On” or “Off.” See Section 8.17
for more
information about Stealth Mode.
Treble Level
“Treble Menu”
Use or to choose speaker treble level (LOW, MEDIUM, MEDHIGH, or HIGH)
.
Press to return to dwell display.
Display
Brightness
“Bright Menu”
Use or to brighten or dim backlighting. Press to return to dwell display.
Side Tone Level
“Side Menu”
Use or to choose side tone level (OFF, LOW, MED, or HIGH). Press
to
return to dwell display.
See Next Page
