PAGE 2.2 - 30 OPERATION MARK IV HD J2 TAMPER
REVISED 10 -2020 JUPITER II BULLETIN 5082505
2.2
2.2.8 Mode Select Panel
2.2.8.3 F3 Pump Control Pressure Button / Panel - See Figure 2.2-19
1. Press the F3 Pump Control Pressure Button on the Mode Select Panel or the
F3 Key on the Right Operator Keypad or computer keyboard to display the
Pump Control Pressure Panel on the screen. The panel displays of the
following:
(1) F1 Pump Pressure Calibration Button: Press the button or the F1 Key on the Right
Operator Keypad or computer keyboard to display the F1 Pump Pressure Calibration
Panel on the screen to calibrate the pumps P1 - P2 proportional control valve.
(2) F2 Pump Pressure Button: Press the button or the F2 Key on the Right Operator
Keypad or computer keyboard to adjust the pumps P1 - P2 traction / work hydraulic
pressure. The Info Box (A) displays the actual traction / work hydraulic pressure.
(3) F3 Pump Static Test Pressure Button: Press the button or the F3 Key on the Right
Operator Keypad or computer keyboard to adjust the pumps P1 - P2 static test
hydraulic pressure. The Info Box (B) displays the actual static test hydraulic pressure.
(4) F4 Pump Run Pressure Button: Press the button or the F4 Key on the Right Operator
Keypad or computer keyboard to operate the pumps P1 - P2 at the desired static test
pressure.
(5) Plus / Minus Buttons: Press the Plus (+) Button or the Plus (+) Key on the Right
Operator Keypad or computer keyboard to increase the pump pressure. Press the
Minus (-) Button or the Minus (-) Key on the Right Operator Keypad or computer
keyboard to decrease the pump pressure.
(6) Pump Pressure Sliders: The pump P1 (left) and pump P2 (right) sliders will highlight
yellow to display the actual pump pressure as it increases or decreases.
(7) Escape Button: Press the button or the Escape Key on the Right Operator Keypad or
computer keyboard to remove this panel from the screen and remain in the previously
selected operating mode.
