MARK IV HD J2 TAMPER OPERATION PAGE 2.1 - 59
BULLETIN 5082505 CONTROLS REVISED 10 - 2020
2.1
2.1.13 Miscellaneous Cab Controls
FIGURE 2.1-37 FIGURE 2.1-38
MASTER CONTROL BOX TROUBLE LIGHT OPTION
STORAGE COMPARTMENT / JUMP SEATS MCB / PDB
FIGURE 2.1-39 FIGURE 2.1-40
FIRE EXTINGUISHER FIRST AID KIT
6
5
2
3
3
1
A
4
POWER
DISTRIBUTION BOX
