PAGE 2.1 - 10 OPERATION MARK IV HD J2 TAMPER
REVISED 10 - 2020 CONTROLS BULLETIN 5082505
2.1
2.1.2 Controls - Exterior
(1) Hand Rails - See Figure 2.1-4
(2) Steps - See Figure 2.1-4
(3) Platforms - See Figure 2.1-4
The machine is equipped with Hand Rails, Steps / Ladders and Walk Platforms located in the
following locations: These features provide safer access to components when performing
maintenance, or when making adjustments or repairs to the machine.
Yellow: Hand Rails
Green: Steps / Ladders
Gray: Walk Platforms
(4) Battery Compartment - See Figure 2.1-4
The Battery Compartment is located on the left side of the machine next to the engine under a
lockable hinged access platform. The compartment houses the batteries, master disconnect
switch and purge cycle indicator.
(5) DEF Tank / Emergency Pump Compartment - See Figure 2.1-4
The Diesel Exhaust Fluid (DEF) / Emergency Pump Compartment is located on the right side of
the machine next to the engine under a lockable hinged access platform. The compartment
houses the engine DEF tank and emergency pump.
(6) Storage Compartments - See Figure 2.1-4
The Storage Compartments are located on the left and right sides of the machine next to the
engine under lockable hinged access platforms. The compartments can be used to store tools,
gauges, repair parts, etc.
