PAGE 2.1 - 52 OPERATION MARK IV HD J2 TAMPER
REVISED 10 - 2020 CONTROLS BULLETIN 5082505
2.1
2.1.11 Operator Keypad Controls - Right - See Figure 2.1-35
(B) Function Key Group - Outlined in MAGENTA
(7) Enter (Accept) Key
The Enter (Accept) Key functions in the same way as any Enter (Accept) Button that is currently
displayed on the screen.
When the Work Mode Panel is displayed on the screen, press and release the Enter Key to
toggle between the 1st, 2nd and 3rd set of Toolbar Buttons.
When a set of Toolbar Buttons is displayed, it will remain displayed for approximately 7-1/2
seconds. If none of the available buttons or functions are selected on the currently displayed
Toolbar, then the 1st set of Toolbar Buttons will be re-displayed again. This Time Out Feature
helps keep the operation of the Function Keys consistent while the machine is being operated
so the Operator does not have to look at the screen in order to activate a frequently used
operation.
(8) Alarm Key
Press and release the Alarm Key, or the F7 Key on the computer keyboard to display the
Expanded Alarm Panel on the screen. In the Expanded Alarm Panel, all of the computer’s past
alarms can be viewed, the computer’s time and date can be changed, and the computer’s
language can be changed, if another language is available. Press the Escape Button on the
displayed panel, or the Escape Key on the Right Operator Keypad or on the computer keyboard
to remove the Expanded Alarm Panel from the screen.
(9) Escape Key
The Escape Key functions in the same way as any Escape Button that is currently displayed on
the screen.
(10) Plus Key
The Plus Key functions in the same way as any Plus Button that is currently displayed on the
screen.
(11) Minus Key
The Minus Key functions in the same way as any Minus Button that is currently displayed on the
screen.
