MARK IV HD J2 TAMPER OPERATION PAGE 2.1 - 43
BULLETIN 5082505 CONTROLS REVISED 10 - 2020
2.1
2.1.9 Operator Keypad Controls - Left
FIGURE 2.1-33
OPERATOR LEFT KEYPAD CONTROLS
N
Auto
4
9 4 7 11 12
10 3 13 8 1
18 5 6 19 2
20 14 15 16 17
