HBM CANHEAD - Notice

Field of application
14 A01185_11_X00_00 HBM: public CANHEAD
CAN bus and power supply (Devicenet)
CANHEAD amplifier modules for single strain
gages or transducers
USB
up to 5
CANHEADs
10 channels per module
Base
module
Amplifier
module
Base
module
Base
module
Amplifier
module
Amplifier
module
max. 250 m
Fig. 4.2 Block diagram of the overall system with CANHEADdirect
Notice
Avoid electrostatic discharge! Ensure that any person or object is electrostati
cally discharged by touching a grounded object, before touching the CAN
HEAD module during measurement. Non‐observance may result in invalid
measured values being supplied for up to 200 ms.
