Internal calculation channels

PMX A4354-2.2 HBM: public 263

Resetting the event counter can be done by:

S Digital input (PX878)

S By a fieldbuscontrol word, this is indicated by digital

inputs 17..32 of the PMX

S other flags of different Calculated Channels.
