Electrical connections PMX

84 A4354-2.2 HBM: public PMX

Piezoelectric sensors with external charge amplifier

(-)

(+)

Cable shield

24 V

PIN:

CMA

charge amplifier

Piezoelectric sensor

Charge cable

Signal +

Signal -

0 V

PX401

TEDS transducer

identification

PX878

Terminal 2

(digital

input/output)

Measurement signal (reset)

Fig. 8.10 PX401 pin assignment with external charge amplifier
