Electrical connections PMX
PMX A4354-2.2 HBM: public 85
External transducers are supplied with power via the
PX401 measurement card (OUT + and OUT -). The
supply voltage is identical to the device supply voltage.
The maximum current is 400 mA per measurement card
and is distributed across the used transducers.
Important
The individual measurement channels on the PX401
measurement card are not electrically isolated from each
other. The PX401 measurement card has common elec
trical isolation from the basic device.
