HCFA Q Series User Manual

27
Table 0-12 Digital input module structure description
The direction of EtherCAT data frame transmission in the digital input module depends on the ESC
(EtherCAT Slave Controller). Check the diagram below, the data frame transmission direction is A→B.
SS
No indicator
S/S input common terminal
SS
No indicator
S/S input common terminal
Item
Name
Description
①
Sheetmetal
Transmits QBUS signal and control circuit current. Do not support hot swap.
②
Connector
connection
Provide wiring device for easy wiring and module replacement
③
Cable tie
Pass the cables through and fix them to make the wiring more neat and
convenient for future maintenance.
Digital input module signal transmission direction
HCQX-ID16-D Front view
A
B
HCQX-ID16-D viewed from the right side
Mounting hook
Mounting hook
Sheetmetal
1
2
Cable tie
Connector
mounting
hook
3
