36
The direction of EtherCAT data frame transmission in the digital output module depends on the ESC
(EtherCAT Slave Controller). Check the diagram below, the data frame transmission direction is A→B
Items
Name
Description
②
Sheetmetal
Transmits QBUS signal
③
Connector
connection
Provide wiring device for easy wiring and module replacement
④
Cable tie
Pass the cables through and fix them to make the wiring more neat and
convenient for future maintenance.
Analog input module signal transmission direction
HCQX-AD04-D Front view
A
B
HCQX-AD04-D viewed from right side
Mounting hook
Mounting
hook
Sheetmetal
5
6
Cable tie
Connector
connection
7
