HCFA Q Series User Manual

51
9
Sub-index 9
RO
UINT
1A08
A
Sub-index 10
RO
UINT
1A09
B
Sub-index 11
RO
UINT
1A0A
C
Sub-index 12
RO
UINT
1A0B
D
Sub-index 13
RO
UINT
1A0C
E
Sub-index 14
RO
UINT
1A0D
F
Sub-index 15
RO
UINT
1A0E
10
Sub-index 16
RO
UINT
1A0F
1C33
SM input parameter
1
Sync. mode
RW
UINT
01
2
Cycle time
RO
UDINT
7122000（DEC）
SM communication cycle
time（ns）
4
Supported sync
mode
RO
UINT
3
Supported sync mode：
0x0001：FREE RUN
0x0002：SM
5
Mini. Cycle time
RO
UDINT
100000（DEC）
（ns）
6
Calculation and copy
time
RO
UDINT
0
8
Obtain cycle time
RW
UINT
0
9
Delay time
RO
UDINT
0
A
SYNC0 cycle time
RW
UDINT
0
B
SM event loss
RO
UINT
0
C
Cycle time too small
RO
UINT
0
20
SYNC error
RO
BOOL
FALSE
6000
Channel 1 status
1
Within range
RO
BOOL
FALSE
2
Over range
RO
BOOL
FALSE
3
Limit 1
RO
BOOL
FALSE
5
Limit 2
RO
BOOL
FALSE
7
Error
RO
BOOL
FALSE
6010
Digital value
RO
INT
0
6020
Max. value
RO
INT
0
6030
Mini. value
RO
INT
0
6040
Channel 2 status
1
Within range
RO
BOOL
FALSE
2
Over range
RO
BOOL
FALSE
3
Limit 1
RO
BOOL
FALSE
5
Limit 2
RO
BOOL
FALSE
7
Error
RO
BOOL
FALSE
6050
Digital value
RO
INT
0
