HCFA Q Series User Manual

70
 High-speed output internal circuit and external wiring diagram
hsi_cnt1
X2
X10
hsi_cnt5
X3
X11
hsi_cnt2
X4
X12
hsi_cnt6
X5
X13
hsi_cnt3
X6
X14
hsi_cnt7
X7
X15
COM
terminal
S/S
S/S
COM
terminal
CAUTION
 The encoder Z-phase can be connected to any ports except AB high-speed input
channels, which requires corresponding setting in the software.
 The total extension distance of high-speed IO extension cables should be within
3m.
 For extension cables, the minimum bending radius of the cable is 76mm or more.
If the bending radius is 76mm, it may cause malfunction due to poor performance,
disconnection, etc.
HSOutput
0
8
HSOutput
1
9
HSOutput
2
10
HSOutput
3
11
HSOutput
4
12
HSOutput
5
13
HSOutput
6
14
HSOutput
7
15
COM
S/S
S/S
Wiring diagram
Internal circuit diagram
-
+
DC24V
*COM is short-circuited internally, and other channels are not connected. Take the channel
8-15 as the example.
Load
