Changed functions 606 42x-01 since the predecessor versions 340 49x-06
HEIDENHAIN iTNC 530 15
Changed functions 606 42x-01 since
the predecessor versions 340 49x-06
In the calibration menus for touch probe length and radius, the
number and name of the active tool are also displayed now (if the
calibration data from the tool table are to be used, MP7411 = 1, see
"Managing more than one block of calibrating data", page 477).
During tilting in the Distance-To-Go mode, the PLANE function now
shows the angle actually left to be traversed until the target position
(see “Position display” on page 385).
The approach behavior during side finishing with Cycle 24 (DIN/ISO:
G124) was changed (see User's Manual for Cycle Programming).
