HEIDENHAIN iTNC 530 169
5.2 Tool Data
Selecting a pocket table in the Programming and
Editing operating mode
U Call the file manager.
U Press the SELECT TYPE soft key to select the file
type.
U Press the soft key TCH FILES (second soft-key row) to
show files of the type .TCH.
U Select a file or enter a new file name. Conclude your
entry with the ENT key or the SELECT soft key.
Abbr. Inputs Dialog
P Pocket number of the tool in the tool magazine -
T Tool number Tool number?
ST Special Tool with a large radius requiring several pockets in the tool
magazine. If your special tool takes up pockets in front of and behind its
actual pocket, these additional pockets need to be locked in column L
(status L)
Special tool?
F Fixed tool number. The tool is always returned to the same pocket in the tool
magazine
Fixed pocket? Yes = ENT /
No = NO ENT
L Locked pocket (see also column ST) Pocket locked Yes = ENT /
No = NO ENT
PLC Information on this tool pocket that is to be sent to the PLC PLC status?
TNAME Display of the tool name from TOOL.T -
DOC Display of the comment to the tool from TOOL.T -
PTYP Tool type. Function is defined by the machine tool builder. The machine tool
documentation provides further information.
Tool type for pocket
table?
P1 ... P5 Function is defined by the machine tool builder. The machine tool
documentation provides further information.
Value?
RSV Pocket reservation for box magazines Pocket reserv.: Yes = ENT
/ No = NOENT
LOCKED_ABOVE Box magazine: Lock the pocket above Lock the pocket above?
LOCKED_BELOW Box magazine: Lock the pocket below Lock the pocket below?
LOCKED_LEFT Box magazine: Lock the pocket at left Lock the pocket at left?
LOCKED_RIGHT Box magazine: Lock the pocket at right Lock the pocket at right?
S1 ... S5 Function is defined by the machine tool builder. The machine tool
documentation provides further information.
Value?
