HEIDENHAIN iTNC 530 195

6.3 Contour Approach and Departure

Example NC blocks

N50 G00 G40 G90 X-30 Y+50 *

Starting point

N60 G01 G41 X+0 Y+50 F350 *

First contour point

N70 G26 R5 *

Tangential approach with radius R = 5 mm

. . .

PROGRAM CONTOUR BLOCKS

. . .

Last contour point

N210 G27 R5 *

Tangential departure with radius R = 5 mm

N220 G00 G40 X-30 Y+50 *

End point
