HEIDENHAIN iTNC 530 293
9.10 Preassigned Q Parameters
Workpiece status Parameter value
Good Q180
Rework Q181
Scrap Q182
Measured deviation with Cycle 440 Parameter value
X axis Q185
Y axis Q186
Z axis Q187
Markers for cycles Q188
Tool measurement with the BLUM laser Parameter value
Reserved Q190
Reserved Q191
Reserved Q192
Reserved Q193
Reserved for internal use Parameter value
Markers for cycles Q195
Markers for cycles Q196
Markers for cycles (machining patterns) Q197
Number of the last active measuring cycle Q198
Status of tool measurement with TT Parameter value
Tool within tolerance Q199 = 0.0
Tool is worn (LTOL/RTOL is exceeded) Q199 = 1.0
Tool is broken (LBREAK/RBREAK is
exceeded)
Q199 = 2.0
