402 Programming: Multiple Axis Machining
12.2 The PLANE Function: Tilting the Working Plane (Software Option 1)
Positioning the rotary axes in a separate block
Proceed as follows if you want to position the rotary axes in a separate
positioning block (option STAY selected):
U Select any PLANE function, and define automatic positioning with the
STAY option. During program execution the TNC calculates the
position values of the rotary axes present on the machine, and
stores them in the system parameters Q120 (A axis), Q121 (B axis)
and Q122 (C axis)
U Define the positioning block with the angular values calculated by
the TNC
NC example blocks: Position a machine with a rotary table C and a
tilting table A to a space angle of B+45°.
Danger of collision!
Pre-position the tool to a position where there is no danger
of collision with the workpiece (clamping devices) during
positioning.
...
12 L Z+250 R0 FMAX
Position at clearance height.
13 PLANE SPATIAL SPA+0 SPB+45 SPC+0 STAY
Define and activate the PLANE function
14 L A+Q120 C+Q122 F2000
Position the rotary axis with the values calculated by
the TNC
...
Define machining in the tilted working plane
