452 Manual Operation and Setup
14.2 Moving the Machine Axes
Entering the spindle speed S
U Press the handwheel soft key F3 (MSF).
U Press the handwheel soft key F2 (S).
U Select the desired speed by pressing the F1 or F2 key. If you press
and hold the respective key, each time it reaches a decimal value 0
the TNC increases the counting increment by a factor of 10. If in
addition you press the CTRL key, the counting increment increases
to 1000.
U Activate the new speed S with the NC start key.
Entering the feed rate F
U Press the handwheel soft key F3 (MSF).
U Press the handwheel soft key F3 (F).
U Select the desired feed rate by pressing the F1 or F2 key. If you
press and hold the respective key, each time it reaches a decimal
value 0 the TNC increases the counting increment by a factor of 10.
If in addition you press the CTRL key, the counting increment
increases to 1000.
U Confirm the new feed rate F with the handwheel soft key F3 (OK).
Datum setting
U Press the handwheel soft key F3 (MSF).
U Press the handwheel soft key F4 (PRS).
U If required, select the axis in which the datum is to be set.
U Reset the axis with the handwheel soft key F3 (OK), or with F1
and F2 set the desired value and then confirm with F3 (OK). By
also pressing the CTRL key, you can increase the counting
increment to 10.
Changing Modes of Operation
With the handwheel soft key F4 (OPM), you can use the handwheel to
switch the mode of operation, provided that the current status of the
control allows a mode change.
U Press the handwheel soft key F4 (OPM).
U Select the desired operating mode by handwheel soft key
îš„ MAN: Manual Operation
îš„ MDI: Positioning with Manual Data Input
îš„ SGL: Program Run, Single Block
îš„ RUN: Program Run, Full Sequence
