User Manual of PanoVu Series Network Camera
3. Configure the rule area:
Click on the tool bar of the live view panel. Click the mouse on the live view panel. Right
click the mouse to finish drawing.
Figure 6-35 Draw Area
4. Set the duration from 1to 100.
5. Enable rules: Check the Enable checkbox of each rule in the rule list to enable the rule.
6. Click to save the settings.
Region Entrance
Purpose:
This function can be used for detecting people, vehicles and objects entering the pre-defined
region. The alarm will be triggered if the rule is broken.
Steps:
1. Create new rule: Click to add a new rule.
2. Select rule type: Click the dropdown list and select Region Entrance as the rule type.
Figure 6-36 Select Rule Type
3. Configure the rule area:
Click on the tool bar of the live view panel. Click the mouse on the live view panel. Right
click the mouse to finish drawing.
