HIKVISION DS-K1T803MF User Manual

Fingerprint Access Control Terminal
62
Blank Card
 Adding Card
Before you start:
Make sure a card dispenser is connected to the PC and is configured already. Refer to the section of Card
Dispenser Configuration5.6.2 System Configuration for details.
Steps:
1. Click the button to add cards.
2. Two modes of adding cards are supported.
Adding Single Card
Choose the Single Add as the adding mode by clicking the to and input the Start Date, Expiring
Date and Card No. in the text field.
Batch Adding Cards
Choose the Bulking Adding as the adding mode by clicking the to and input the activation
date, expiry date, start card No. and last card No. in the corresponding text fields.
Note: The start card No. and the last card No. should be the with same length. E.g., the last card No.
is 234, then the start card No. should be like 028.
3. Click the button to finish adding.
4. Click an added blank card in the list and click button to issue the card with a person.
Note: you can double click the blank card in the card list to enter the Issue Card Page.

HIKVISION DS-K1T803MF Specifications

General

Type	Basic access control reader
Product color	Black
Cards capacity	3000 cards
Fingerprint reader	Yes
Authentication type	Access chip/card, Biometric, Password
Fingerprint sensor type	Optical
False Rejection Rate (FRR)	0.01 %
False Acceptance Rate (FAR)	0.001 %
Access chip/card reader type	Contactless
Contactless working distance	50 mm
International Protection (IP) code	IP42
PC connected	-
Ethernet LAN data rates	10, 100 Mbit/s
Display type	TFT-LCD
Display diagonal	2.4 \
Maximum resolution	320 x 240 pixels
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Front camera	No
DC current (max)	1 A

Weight and Dimensions

Depth	37 mm
Width	76.5 mm
Height	205 mm
