HIKVISION DS-K1T803MF User Manual

Fingerprint Access Control Terminal
63
5. Click to choose a person on your demand in the popup dialog box, select a fingerprint, and click
to finish.
Notes:
 The issued card will disappear from the Blank Card list, you can check the card information in
the Normal Card list.
 Up to 2000 cards can be added.
 For the DS-K1A801 device and the DS-K1T803 device, the card and the user are mapped in one-
to-one relationship.
 Deleting Card
You can click an added blank card in the list and click button to delete the selected card.
Normal Card
Click the Normal tab in the card managemet interface to show the Normal Card list. You can view all the
issued card information, including card No., card holder, and the department of the card holder.
 Click to select a card and click the Card Change button to change the associated card for card holder.
Select another card in the popup window to replace the current card.
 Click to select an issued card and click the Return Card button to cancel the assotiation of the card,
then the card will disappear from the Normal Card list, which you can find it in the Blank Card list.
 Click to select an issued card and click the Report Card Loss button to set the card as the Lost Card,
that is, an invalid card.

HIKVISION DS-K1T803MF Specifications

General

Type	Basic access control reader
Product color	Black
Cards capacity	3000 cards
Fingerprint reader	Yes
Authentication type	Access chip/card, Biometric, Password
Fingerprint sensor type	Optical
False Rejection Rate (FRR)	0.01 %
False Acceptance Rate (FAR)	0.001 %
Access chip/card reader type	Contactless
Contactless working distance	50 mm
International Protection (IP) code	IP42
PC connected	-
Ethernet LAN data rates	10, 100 Mbit/s
Display type	TFT-LCD
Display diagonal	2.4 \
Maximum resolution	320 x 240 pixels
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Front camera	No
DC current (max)	1 A

Weight and Dimensions

Depth	37 mm
Width	76.5 mm
Height	205 mm
