5.2 Checking Recorded Data
116
The type of manual record is identified
as follows.
For logging records, only the last data is
displayed.
3. To view data not displayed on the
screen, press the keys shown in the
table below
When neither
[STEP] or [TC] is
off.
Standard measurement
data
When [TC] is on. Temperature correction
data
When [STEP] is on. Step voltage test data
Standard Measurement Data
Indications to be switched Keys used
key
Elapsed time Temperature/humidity
key
Date of measurement Measurement time Data
key
Return to the standby screen.
key
Test voltage setting Actual output voltage
(Ex. 5.00 kVSET 5.25 kV)
Automatic
switching
Insulation
resistance
Leakage current
DAR 1 min/ 30 s
PI (10/1 min)
DAR 1 min/15 s
Manual recording
Logging recording
Insulation
resistance
Leakage
current
