3.2 Measuring Insulation Resistance
64
3.2.2 Ending Measurement
Procedure
1. Press the key with the test leads
connected to the object under test.
The last measurement is held.
( lights up.)
2. Immediately after measurement has
been completed, the discharge circuit in
the tester automatically discharges the
electric charge remaining in the object
under test.
See 3.2.4 "Automatic Discharge Function" (page
67).
3. During discharge, the mark and
key lamp blinks.
The voltage indication shows the progress
of discharge.
To Next Page
