3.2 Measuring Insulation Resistance
1
2
3
4
5
6
7
8
9
10
11
付録
索引
65
4. When the voltage falls to about 10 V, the
tester stops discharging and the mark
and key lamp are turned off.
5. To restart measurement, press the
key to check the test voltage before
resuming measurement.
• If the key is pressed during measurement,
automatic discharge is performed before power is
turned off.
• If the battery runs low during measurement, the
tester automatically stops measurement. Automatic
discharge is performed and then [LObAt] appears on
the screen.
LastElapsed time of the
Actual output
voltage
(last measurement)
end of measurement measurement value
