Hioki 3455 - Logging Recording (Recording at Regular Intervals)

5.1 Recording Measurement Data
106
5.1.2 Logging Recording (Recording at
regular intervals)
The tester stores insulation resistance data
at set intervals.
• A total of 10 data numbers are used for
logging records; Lr0 to Lr9.
• Each record contains up to 360 loggings.
Selectable recording intervals:
15 sec., 30 sec., 1 min.,2 min., 5 min.
• Maximum number of loggings and maxi-
mum recording time vary depending on
set recording interval.
(The timer is off.)
• When the timer is set, the tester automat-
ically stops measurement after the set
time has elapsed.
Selectable time: 30 sec. to 30 min. or
OFF (When setting to more than 1
minute, the time increments or decre-
ments by 1 minute.)
Recording
interval
Maximum
number of
loggings
Maximum
recording
time
15 sec. 360 times 90 min.
30 sec. 360 times 3 hours
1 min. 360 times 6 hours
2 min. 250 times 8 hours and
20 min.
5 min. 100 times 8 hours and
20 min.
